Type：rigid Solar Panel
Cell size：156*156mm
Junction Box type：Pass the TUV certificate
VMP：32.6
IMP：9.19
VOC：40
ISC：9.85
Frame：Anodized Aluminium Alloy
Junction Box：IP67 Rated
QYY- 18V 24V 36V 48V 100watt 250watt 300wattSolar Panel
Specifications：
| Model | 275M | 280M | 285M | 290M | 300M |
| Rated Maximum Power at STC | 275W | 280W | 285W | 290W | 300W |
| Maximum Power Voltage (Vmp) | 31.5V | 31.7V | 31.8V | 32.2V | 32.6V |
| Maximum Power Current (Imp) | 8.73A | 8.84A | 8.97A | 9.01A | 9.19A |
| Open Circuit Voltage ( Voc) | 38.1V | 38.4V | 38.5V | 38.9V | 40V |
| Short Circuit Current (Isc) | 9.39A | 9.42A | 9.51A | 9.66A | 9.85A |
| Module Efficiency | 16.90% | 17.10% | 17.40% | 17.70% | 18.60% |
| Power Tolerance | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% |
| STC: Irradiance 1000W/m², Module Temperature 25°c, Air Mass 1.5 | |||||
